RTiDock iPod Docking Station
This model has been discontinued
The RTiDock is the essential accessory for any professionally installed distributed audio system. With the popularity of the iPod® and increasing demand from consumers to enjoy the device through the music systems in their home or business, convenient and reliable integration is a must. Designed from the ground up with the professional integrator in mind, the RTiDock provides the perfect solution, allowing consumers to connect their iPod® to their local or distributed audio system and control it through an RTI in-wall or handheld controller.
- On-screen interface (GUI) for navigation of music on a TV display.
- Sliding tray provides a clean look and improved reliability.
- VirtualSync technology allows synching with iTunes over the network.
- Compatible with iPod Classic®, iPod Nano®, iPod Touch®.
- Analog and digital audio output connectors.
- Built-in IR receiver and 3.5mm mini-jack for IR control.
- Supports, IR/RS-232/Ethernet control.
- Blue LED base emits a cool glow.
- Slim design allows rack mounting, or may be used free standing.
- Charges ipod battery.
- Screen saver mode shows album art on television display
- Field-upgradable firmware.
| Dock DC Voltage | 12VDC, 2A |
| Charge Power Supplied | 5VDC, 1A |
| Connection for iPod | Cable with connector overmold |
| USB | Type A, Future use |
| Ethernet | 10Base-T/100Base TX, RJ45 |
| RS-232 Control | RJ45 |
| Analog Audio Output (Stereo) | Two (2), RCA |
| SPDIF Digital Audio Output | One (1), RCA |
| Component Video Output (Y/Pr/Pb) | Three (3), RCA (480p) |
| IR Inputs |
One (1), IR Sensor |
| Disconnected Indicator | Solid Red LED |
| RTiSync In-Progress Indicator | Flashing Red LED |
| Network Indicator | Two(2), LED (Orange/Green) |
| Decorative Base Lighting | Blue LEDs |
| Reset switch | One(1), Rear push button |
| Operating Temperature | +41F to +104F (+5C to +40C) |
| Operating Humidity | 20% to 80% RH |
| Dimensions HxWxD | 1.25in(25mm) x 7.5in(150mm) x 7.5in(150mm) |
| Weight | >25 Watts @ 1KHz (RMS, 2 chan driven 8ohms) |
| Warranty | One Year (parts & labor) |
